Maestro Mix Plus
TECHNICAL SPECIFICATIONS
-
Pumping Capacity: 27 L/min
-
Pumping Capacity (with Alternative Pump): 32 L/min
-
Pumping Distance (Horizontal): 40 m (Maximum)
-
Operating Voltage: 380 V, 50 Hz
-
Pump Motor: 5.50 kW
-
Mixer Motor: 0.55 kW
-
Protection Fuse: 3 × 32 A
-
Water Pump: 0.50 HP
-
Compressor: 0.90 kW, 250 L/min, 6 bar
-
Hopper Capacity: 150 liters
-
Length: 1250 mm
-
Width: 750 mm
-
Height: 1620 mm
-
Filling Height: 950 mm
-
Weight: 300 kg
Maestromix Plus 380V – Powerful, Fast, and Professional Plastering Solution
With its high-performance motor structure and powerful pumping capacity, Maestromix Plus 380V provides speed and efficiency in professional plastering applications. Offering a pumping capacity of 27 liters per minute, and up to 32 liters with the use of an alternative pump, it easily adapts to an intensive work pace.
A pumping pressure of 30 bar and a horizontal conveying distance of up to 40 meters helps deliver the mortar to the application area in a powerful and uniform manner. While its 5.50 kW pump motor delivers high performance, the 0.55 kW mixer motor supports the preparation of the mortar in a homogeneous consistency.
The machine’s large 150-liter hopper capacity reduces the need for continuous material replenishment, making work time efficient. Its 0.90 kW compressor offers powerful support for spraying applications with an air capacity of 250 liters per minute and a working pressure of 6 bar.
Thanks to its durable body, mobile wheel system, and practical design, it can be easily transported in construction site environments. Despite its compact dimensions, Maestromix Plus 380V, which provides high production capacity, is a powerful, reliable, and long-lasting solution for professional businesses in plastering, mortar mixing, pumping, and spraying processes.
